10mm Air Sampling Test Point
10mm Air Sampling Test Point
POA
Air Sampling Test Point with Discrete Cap
- Visible test point with label indication
- Secured via nut or with screws
- White to match most ceilings
- Lightweight
- Easy to install
Learn about the VESDA Air Sampling Test Point with Discrete Cap in the
Eurofyre Knowledge Base
Learn about the VESDA Air Sampling Test Point with Discrete Cap in the
Knowledge BaseDescription
The Eurofyre 10mm Air Sampling Test Point is a key component for aspirating smoke detection (ASD) systems, used with 10mm capillary pipe during smoke testing. This visible test point features a discrete end cap for removal during testing, designed for straightforward, discreet installation.
It features a clear label for identification. It fixes to ceiling tiles via a supplied nut or to ceilings with screws. Lightweight (0.02kg) and white, it blends with most ceilings. The unit operates effectively within a wide temperature range of -40°C to 70°C.
Eurofyre, an authorised Honeywell distributor and a major technical wholesaler of Xtralis products since 2007, supplies this test point. The company offers comprehensive support for VESDA, FAAST, and ICAM aspirating smoke detection systems, encompassing expert advice, pipework calculations, demonstrations, training, and dedicated after-sales service.
Additional information
| Weight | 0.50 kg |
|---|---|
| Dimensions | 16 × 13 × 10 cm |
| Application | Agricultural, Commercial, Education, Government, Hazardous Environments, Healthcare, Heritage, Hospitality, Industrial, Information Technology, Leisure, Marine, Office, Offshore, Public Buildings, Residential, Retail, Transport |
| Colour | White |
| Country of Origin | United Kingdom |
| Environment | Indoors |
| HS Code | 39174000 |
| Material | ABS |
| Mounting | Surface |
| Outer Diameter | 10mm |
| Product | Sampling Point |
| Standards | EN54-20 |
| System | Aspirating Smoke Detection |
| Unit | Piece |
