SenTRI IP66 Sounder VAD
SenTRI IP66 Sounder VAD
POA
- IP66 rated for outdoor and harsh environments
- Combined sounder and visual alarm
- Loop powered with up to 200 devices per loop
- Adjustable sound output via infrared remote
- Active monitoring of sounder and VAD circuits
Learn about the SenTRI IP66 Sounder VAD in the
Eurofyre Knowledge Base
Learn about the SenTRI IP66 Sounder VAD in the
Knowledge BaseDescription
The SenTRI IP66 Sounder VAD is an addressable fire alarm device that combines an audible sounder and visual alarm beacon in one unit. It is loop powered, with no separate power supply required, and supports up to 200 devices per loop depending on load. With an IP66 rating, it is suitable for outdoor and harsh environments. The sounder provides up to 103 dB at 1 metre and can be set to high, medium or low output using an infrared remote. The visual alarm is available with a red or white flash at 0.5 Hz. The device actively monitors both sounder and VAD circuits for system integrity and complies with EN54-3, EN54-23 and EN54-17 standards. It operates in temperatures from -10°C to +50°C.
Additional information
| Application | Agricultural, Commercial, Education, Government, Healthcare, Heritage, Hospitality, Industrial, Information Technology, Leisure, Office, Public Buildings, Residential, Retail, Transport |
|---|---|
| Approval Body | CE, LPCB |
| Brand | |
| Cable Entries | 4 |
| Colour | Red |
| Country of Origin | Romania |
| Environment | Outdoors |
| Input Voltage | 42VDC |
| IP Rating | IP66 |
| Material | Polycarbonate |
| Mounting | Surface |
| Product | Wired Sounder, Wired VAD |
| Protocol | Managed Protocol |
| Short Circuit Isolator | Yes |
| Sound Output | 103dBA |
| Standards | EN54-17, EN54-23, EN54-3 |
| System | Fire Detection |
| System Category | Addressable |
| System Protocol | SenTRI |
| VAD Classification | Wall Mounted |
| Wiring | Loop |
| Unit | Piece |
| Flash Colour | Red Flash, White Flash |
| Indication | LED |
| VAD Power | High, Low, Medium |
| Kind | Wall |
